[해피CGI][cgimall] Flexbox Cheatsheet (플렉스박스 치트시트)

Flexbox의 다양한 속성을 시각적으로 이해할 수 있게 구성된 가이드로, 실습하며 배울 수 있는 자료입니다.

이 자료는 Flexbox의 기본 개념인 display 설정부터 방향을 결정하는 flex-direction, 여러 줄 배치를 위한 flex-wrap, 주 축 정렬을 위한 justify-content, 교차 축 정렬을 위한 align-items와 align-content 같은 핵심 속성들을 직관적으로 보여줍니다. 또한, 아이템 순서를 바꾸는 order, 공간 비율을 조절하는 flex-grow와 flex-shrink, 아이템 기본 크기를 설정하는 flex-basis와 이를 한 번에 쓰는 flex 단축 속성도 다루며, 개별 아이템 정렬을 위한 align-self까지 설명합니다. 각 속성이 실제로 어떻게 배치에 영향을 주는지 예제를 통해 바로 확인할 수 있어, Flexbox를 처음 배우거나 헷갈리는 사람에게 매우 유용한 자료입니다.

HTML 구조

<div class="container">

  <div class="list">

    <div class="list-item">

      <div class="icon">

        <svg viewBox="0 0 24 24" fill="none" stroke="currentColor">

          <path d="M13 2H6a2 2 0 0 0-2 2v16a2 2 0 0 0 2 2h12a2 2 0 0 0 2-2V9z" stroke-width="2"/>

          <path d="M13 2v7h7" stroke-width="2"/>

        </svg>

      </div>

      <div class="content">

        <div class="title">Camping</div>

        <div class="subtitle">Yosemite Park</div>

      </div>

      <div class="date">5 August</div>

    </div>



    <div class="list-item">

      <div class="icon">

        <svg viewBox="0 0 24 24" fill="none" stroke="currentColor">

          <path d="M21 10c0 7-9 13-9 13s-9-6-9-13a9 9 0 0 1 18 0z" stroke-width="2"/>

          <circle cx="12" cy="10" r="3" stroke-width="2"/>

        </svg>

      </div>

      <div class="content">

        <div class="title">Boating</div>

        <div class="subtitle">Lake Tahoe Park</div>

      </div>

      <div class="date">2 August</div>

    </div>



    <div class="list-item">

      <div class="icon">

        <svg viewBox="0 0 24 24" fill="none" stroke="currentColor">

          <path d="M8.5 14.5A2.5 2.5 0 0011 12c0-1.38-.5-2-1-3-1.072-2.143-.224-4.054 2-6 .5 2.5 2 4.9 4 6.5 2 1.6 3 3.5 3 5.5a7 7 0 11-14 0c0-1.153.433-2.294 1-3a2.5 2.5 0 002.5 2.5z" stroke-width="2"/>

        </svg>

      </div>

      <div class="content">

        <div class="title">Barbeue</div>

        <div class="subtitle">Greenfield Shores</div>

      </div>

      <div class="date">28 July</div>

    </div>

  </div>



  <button class="show-hide-btn">

    <span class="show">Show All</span>

    <span class="hide">Hide</span>

    <svg width="16" height="16" viewBox="0 0 16 16" fill="none" stroke="currentColor">

      <path d="M4 6l4 4 4-4" stroke-width="2" stroke-linecap="round" stroke-linejoin="round"/>

    </svg>

  </button>

</div>

CSS 소스

body {

  font-family: system-ui, -apple-system, sans-serif;

  display: grid;

  place-items: center;

  min-height: 100vh;

  margin: 0;

  background: #fafafa;

}



.container {

  background: white;

  border-radius: 24px;

  padding: 24px;

  width: 400px;

  box-shadow: rgba(0, 0, 0, 0) 0px 0px 0px 0px, rgba(0, 0, 0, 0) 0px 0px 0px 0px, rgba(0, 0, 0, 0.1) 0px 4px 6px -1px, rgba(0, 0, 0, 0.1) 0px 2px 4px -2px;

  view-transition-name: container;



  .list-item:nth-child(1) {

    margin-bottom: -21.5%;

  }



  .list-item:nth-child(2) {

    margin-bottom: -21.5%;

    transform: scale(0.95);

  }



  .list-item:nth-child(3) {

    transform: scale(0.9);

  }



  .hide {

    display: none;

  }



  &.expanded {

    .list-item:nth-child(1),

    .list-item:nth-child(2) {

      margin-bottom: 0;

      transform: scale(1);

    }



    .list-item:nth-child(3) {

      transform: scale(1);

    }



    .show {

      display: none;

    }



    .hide {

      display: block;

    }



    .show-hide-btn svg {

      transform: rotate(180deg);

      transition: transform 0.6s;

    }

  }

}



.list {

  display: flex;

  flex-direction: column;

  gap: 16px;

  view-transition-name: list;

}



.list-item {

  display: flex;

  align-items: center;

  gap: 16px;

  padding: 16px;

  background: white;

  border-radius: 16px;

  border: 1px solid #e4e4e7;

  cursor: pointer;

  box-shadow: rgba(0, 0, 0, 0) 0px 0px 0px 0px, rgba(0, 0, 0, 0) 0px 0px 0px 0px, rgba(0, 0, 0, 0.1) 0px 4px 6px -1px, rgba(0, 0, 0, 0.1) 0px 2px 4px -2px;

}



.list-item:nth-child(1) {

  view-transition-name: list-item-1;

  z-index: 2;

}



.list-item:nth-child(2) {

  view-transition-name: list-item-2;

  z-index: 1;

}



.list-item:nth-child(3) {

  view-transition-name: list-item-3;

  z-index: 0;

}



.icon {

  width: 48px;

  height: 48px;

  background: #18181b;

  border-radius: 12px;

  display: grid;

  place-items: center;

}



.icon svg {

  width: 24px;

  height: 24px;

  color: white;

}



.content {

  display: flex;

  flex-direction: column;

  gap: 4px;

  flex: 1;

}



.title {

  font-size: 16px;

  font-weight: 500;

  color: #18181b;

}



.subtitle {

  font-size: 14px;

  color: #71717a;

}



.date {

  font-size: 14px;

  color: #71717a;

  text-align: right;

}



.show-hide-btn {

  display: flex;

  align-items: center;

  justify-content: center;

  gap: 8px;

  padding: 12px 24px;

  margin: 8px auto 0 auto;

  width: 140px;

  background: none;

  color: #71717a;

  border: 1px solid #e4e4e7;

  border-radius: 24px;

  font-weight: 500;

  font-size: 14px;

  cursor: pointer;

  view-transition-name: show-hide-btn;



  span {

    display: inline-block;

    text-align: center;

    width: fit-content;

  }



  svg {

    transition: transform 0.3s;

    view-transition-name: show-hide-btn-icon;

  }

}



.container.expanded .show-hide-btn svg {

  transform: rotate(-180deg);

}



.show,

.hide {

  width: fit-content;

  view-transition-name: button-label;

}



@keyframes fade-out {

  0% {

    opacity: 1;

  }

  10% {

    opacity: 0;

  }

  100% {

    opacity: 0;

  }

}



::view-transition-group(*) {

  animation-duration: 0.6s;

  animation-timing-function: linear(0, 0.402 7.4%, 0.711 15.3%, 0.929 23.7%, 1.008 28.2%, 1.067 33%, 1.099 36.9%, 1.12 41%, 1.13 45.4%, 1.13 50.1%, 1.111 58.5%, 1.019 83.2%, 1.004 91.3%, 1);

}



::view-transition-old(*),

::view-transition-new(*) {

  height: 100%;

}



::view-transition-old(button-label),

::view-transition-new(button-label) {

  width: fit-content;

}



::view-transition-old(button-label) {

  animation-name: fade-out;

  animation-duration: 0.6s;

}

JS 소스

body {

  font-family: system-ui, -apple-system, sans-serif;

  display: grid;

  place-items: center;

  min-height: 100vh;

  margin: 0;

  background: #fafafa;

}



.container {

  background: white;

  border-radius: 24px;

  padding: 24px;

  width: 400px;

  box-shadow: rgba(0, 0, 0, 0) 0px 0px 0px 0px, rgba(0, 0, 0, 0) 0px 0px 0px 0px, rgba(0, 0, 0, 0.1) 0px 4px 6px -1px, rgba(0, 0, 0, 0.1) 0px 2px 4px -2px;

  view-transition-name: container;



  .list-item:nth-child(1) {

    margin-bottom: -21.5%;

  }



  .list-item:nth-child(2) {

    margin-bottom: -21.5%;

    transform: scale(0.95);

  }



  .list-item:nth-child(3) {

    transform: scale(0.9);

  }



  .hide {

    display: none;

  }



  &.expanded {

    .list-item:nth-child(1),

    .list-item:nth-child(2) {

      margin-bottom: 0;

      transform: scale(1);

    }



    .list-item:nth-child(3) {

      transform: scale(1);

    }



    .show {

      display: none;

    }



    .hide {

      display: block;

    }



    .show-hide-btn svg {

      transform: rotate(180deg);

      transition: transform 0.6s;

    }

  }

}



.list {

  display: flex;

  flex-direction: column;

  gap: 16px;

  view-transition-name: list;

}



.list-item {

  display: flex;

  align-items: center;

  gap: 16px;

  padding: 16px;

  background: white;

  border-radius: 16px;

  border: 1px solid #e4e4e7;

  cursor: pointer;

  box-shadow: rgba(0, 0, 0, 0) 0px 0px 0px 0px, rgba(0, 0, 0, 0) 0px 0px 0px 0px, rgba(0, 0, 0, 0.1) 0px 4px 6px -1px, rgba(0, 0, 0, 0.1) 0px 2px 4px -2px;

}



.list-item:nth-child(1) {

  view-transition-name: list-item-1;

  z-index: 2;

}



.list-item:nth-child(2) {

  view-transition-name: list-item-2;

  z-index: 1;

}



.list-item:nth-child(3) {

  view-transition-name: list-item-3;

  z-index: 0;

}



.icon {

  width: 48px;

  height: 48px;

  background: #18181b;

  border-radius: 12px;

  display: grid;

  place-items: center;

}



.icon svg {

  width: 24px;

  height: 24px;

  color: white;

}



.content {

  display: flex;

  flex-direction: column;

  gap: 4px;

  flex: 1;

}



.title {

  font-size: 16px;

  font-weight: 500;

  color: #18181b;

}



.subtitle {

  font-size: 14px;

  color: #71717a;

}



.date {

  font-size: 14px;

  color: #71717a;

  text-align: right;

}



.show-hide-btn {

  display: flex;

  align-items: center;

  justify-content: center;

  gap: 8px;

  padding: 12px 24px;

  margin: 8px auto 0 auto;

  width: 140px;

  background: none;

  color: #71717a;

  border: 1px solid #e4e4e7;

  border-radius: 24px;

  font-weight: 500;

  font-size: 14px;

  cursor: pointer;

  view-transition-name: show-hide-btn;



  span {

    display: inline-block;

    text-align: center;

    width: fit-content;

  }



  svg {

    transition: transform 0.3s;

    view-transition-name: show-hide-btn-icon;

  }

}



.container.expanded .show-hide-btn svg {

  transform: rotate(-180deg);

}



.show,

.hide {

  width: fit-content;

  view-transition-name: button-label;

}



@keyframes fade-out {

  0% {

    opacity: 1;

  }

  10% {

    opacity: 0;

  }

  100% {

    opacity: 0;

  }

}



::view-transition-group(*) {

  animation-duration: 0.6s;

  animation-timing-function: linear(0, 0.402 7.4%, 0.711 15.3%, 0.929 23.7%, 1.008 28.2%, 1.067 33%, 1.099 36.9%, 1.12 41%, 1.13 45.4%, 1.13 50.1%, 1.111 58.5%, 1.019 83.2%, 1.004 91.3%, 1);

}



::view-transition-old(*),

::view-transition-new(*) {

  height: 100%;

}



::view-transition-old(button-label),

::view-transition-new(button-label) {

  width: fit-content;

}



::view-transition-old(button-label) {

  animation-name: fade-out;

  animation-duration: 0.6s;

}
